Home / All / Railway Grinding Wheel / Rail Grinder Wheel MRC-L260090 High-Precision for Jinying96X Grinder

Rail Grinder Wheel MRC-L260090 High-Precision for Jinying96X Grinder

Share
Categories	Railway Grinding Wheel
Brand	Railway Maintenance Equipment & Solutions
Model	MRC-L260090
Category	Rail Grinder
Process	Hot Pressing
Materials	Aluminum Matrix + Zirconia + Glass Fiber
Hardness-Material Identification	Z/A F16Y5B
Granularity	16 Grit
Packaging	Wooden Case
Certification	ISO
Business Model	Customization
Compatible Machine	Jinying96X
Heavy Haul Railway	Axle Load Capacity ≥ 30t

Contact Now

Detail Information

Molaton RailCare-L260090 Rail Grinder Wheel Product Description

Molaton RailCare-L260090: High-Precision Grinding Wheel for Jinying96X

The Molaton RailCare-L260090 is a high-precision rail grinder wheel, specifically developed for the Jinying96X grinding machine. Engineered with advanced zirconia-alumina (ZA) abrasive technology and hot-press resin bonding, it delivers exceptional wear resistance, consistent metal removal, and extended service life on high-speed and heavy-haul rail networks.

Molaton RailCare-L260090 Rail Grinder Wheel Specifications

Technical Specifications
OD x Thickness x Bore	260 x 90 x 154 mm
Gross Weight	9.82 kg
Max Speed	50 m/s
Abrasive	Zirconia Alumina (ZA)
Bond	Resin, Hot Press, Glass Fiber Reinforced
Compatible Systems	Jinying96X Grinder

Key Features & Benefits

Jinying96X Optimized: Precision-engineered bore and fit for Jinying96X spindle specifications
Extended Wheel Life: Zirconia-alumina hot-press formulation delivers 20-30% longer service life vs. standard wheels
Consistent Profile: Maintains rail head geometry through uniform wear characteristics
High Metal Removal Rate: Coarse 16-grit structure enables efficient stock removal in fewer passes
Dynamic Balance: Every wheel balanced for vibration-free operation at 50 m/s
Safety Certified: Fully compliant with GB/T 2492-2017, GB 2494-2014, and Q/CR 1-2014
